SIMATIC Process Control System
IPC847E; (Rack PC, 19, 4U),
Interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x Display Port; 1x
COM, Audio; 4x USB3.1 Gen2
(Type A); 2x USB3.1 (Type C)
backside; 2x USB3.1 (Type A)
frontside; 1x USB3.1 (Type A)
internal; Temperature and fan
monitoring, Watchdog, card
retainer;
Core i7-8700 (6C/12T, 3.2 (4.6)
GHz, 12 MB cache, TB, AMT) -
PCS 7 OS server, engineering
server, web server;
960 GB SSD 2.5 SATA;
drive support for installation
internal, 0.5 g vibration, 5 g
shock;
16 GB DDR4 SDRAM (2x 8 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), with restore
USB flash drive;
bus module 11 slots: 3x PCI, 1x
PCIe x16 (8 L), 5x PCIe x16 (4
L), 2x PCIe x4 (4 L);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC647E; (Rack PC, 19, 2U),
Interfaces: 3x Gbit LAN (RJ45),
M.2 PCIe x4 1x DVI-D, 2x
Display Port; 1x COM, Audio; 4x
USB3.1 Gen2 (Type A); 2x USB3.1
(Type C) backside; 2x USB3.1
(Type A) frontside; 1x USB3.1
(Type A) internal; Temperature
and fan monitoring, Watchdog,
card retainer;
Core i7-8700 (6C/12T, 3.2 (4.6)
GHz, 12 MB cache,TB, AMT) PCS 7
ES/OS Single Station, OS
Client;
480 GB SSD 2.5 SATA;
drive support for internal
installation, 0.5 g vibration,
5 g shock;
16 GB DDR4 SDRAM (2x 8 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows 10 Enterprise 2019
LTSC, MUI (en, de, fr, it, sp,
zh), 64-bit, with restore USB
flash drive;
bus module 4 slots: 2x PCI, 2x
PCIe x16 (8 L);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC process control system
IPC547J; (rack PC, 19, 4 U),
interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x display port; 1x
COM, audio; 6x USB 3.1 Gen. 2
(2x type C, 4x type A) on the
rear side, 2x USB3.1 Gen.1
(type A) on the front, 2x USB
2.0 internal; 7 slots: 5x PCIe,
2x PCI, internal, temperature
and fan monitoring watchdog,
card retainer;
Xeon W-1270E (8C/16T, 3.4 (4.8)
GHz, 16 MB cache), MB (Chipset
W480E), iAMT, PCS 7 OS server
RAID1, 2x 960 GB SSD 2.5 SATA;
drive support for rack units on
the front;
32 GB DDR4 SDRAM (2x 16 GB),
dual channel;
PCS 7 V9.1 SP1 preinstalled;
Windows Server IoT 2019
Standard Edition including 16
cores, 5 clients, 64-bit, MUI
(en, de, fr, it, sp, zh),
64-bit, with restore USB flash
drive;
enclosure blue chromated,
Industrial Ethernet (CP1623),
(1 slot occupied);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC process control system
IPC547J; (rack PC, 19, 4 U),
interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x display port; 1x
COM, audio; 6x USB 3.1 Gen. 2
(2x type C, 4x type A) on the
rear side, 2x USB3.1 Gen.1
(type A) on the front, 2x USB
2.0 internal; 7 slots: 5x PCIe,
2x PCI, internal, temperature
and fan monitoring watchdog,
card retainer;
Xeon W-1270E (8C/16T, 3.4 (4.8)
GHz, 16 MB cache), MB (Chipset
W480E), iAMT, PCS 7 ES/OS
Single Station, OS client;
RAID1, 2x 960 GB SSD 2.5 SATA;
drive support for rack units on
the front;
16 GB DDR4 SDRAM (2x 8 GB),
dual channel;
PCS 7 V9.1 SP1 preinstalled;
Windows 10 IoT Enterprise 2019
LTSC, MUI (en, de, fr, it, sp,
zh), 64-bit, with restore USB
flash drive, (for Processor
Core i7 / Xeon);
enclosure blue chromated,
Industrial Ethernet (CP1623),
(1 slot occupied);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC process control system
IPC547J; (rack PC, 19, 4 U),
interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x display port; 1x
COM, audio; 6x USB 3.1 Gen. 2
(2x type C, 4x type A) on the
rear side, 2x USB3.1 Gen.1
(type A) on the front, 2x USB
2.0 internal; 7 slots: 5x PCIe,
2x PCI, internal, temperature
and fan monitoring watchdog,
card retainer;
Core i7-10700E (8C/16T, 2.9
(4.5) GHz, 16 MB cache), MB
(Chipset W480E), iAMT, PCS 7
ES/OS Single Station, OS
client;
480 GB SSD 2.5 SATA;
drive support for internal
installation, 0.5 G vibration,
5 g shock;
16 GB DDR4 SDRAM (2x 8 GB),
dual channel;
PCS 7 V9.1 SP1 preinstalled;
Windows 10 IoT Enterprise 2019
LTSC, MUI (en, de, fr, it, sp,
zh), 64-bit, with restore USB
flash drive, (for Processor
Core i7 / Xeon);
enclosure blue chromated,
without expansions;
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC647E; (Rack PC, 19, 2U),
Interfaces: 3x Gbit LAN (RJ45),
M.2 PCIe x4 1x DVI-D, 2x
Display Port; 1x COM, Audio; 4x
USB3.1 Gen2 (Type A); 2x USB3.1
(Type C) backside; 2x USB3.1
(Type A) frontside; 1x USB3.1
(Type A) internal; Temperature
and fan monitoring, Watchdog,
card retainer;
Core i5-8500 (6C/6T, 3.0 (4.1)
GHz, 9 MB cache, TB, AMT) PCS 7
ES/OS Single Station, OS
Client;
1 TB HDD [Enterprise] 3.5 SATA;
drive support for internal
installation, 0.5 g vibration,
5 g shock;
16 GB DDR4 SDRAM (2x 8 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows 10 Enterprise 2019
LTSC, MUI (en, de, fr, it, sp,
zh), 64-bit, without restore
USB flash drive;
bus module 4 slots: 2x PCI, 2x
PCIe x16 (8 L);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC647E; (Rack PC, 19, 2U),
Interfaces: 3x Gbit LAN (RJ45),
M.2 PCIe x4 1x DVI-D, 2x
Display Port; 1x COM, Audio; 4x
USB3.1 Gen2 (Type A); 2x USB3.1
(Type C) backside; 2x USB3.1
(Type A) frontside; 1x USB3.1
(Type A) internal; Temperature
and fan monitoring, Watchdog,
card retainer;
Core i7-8700 (6C/12T, 3.2 (4.6)
GHz, 12 MB cache,TB, AMT) PCS 7
ES/OS Single Station, OS
Client;
RAID1, 2x 1 TB HDD [Enterprise]
3.5 SATA;
drive support for rack units on
the front;
16 GB DDR4 SDRAM (2x 8 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows 10 Enterprise 2019
LTSC, MUI (en, de, fr, it, sp,
zh), 64-bit, without restore
USB flash drive;
bus module 4 slots: 2x PCI, 2x
PCIe x16 (8 L);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC647E; (Rack PC, 19, 2U),
Interfaces: 3x Gbit LAN (RJ45),
M.2 PCIe x4 1x DVI-D, 2x
Display Port; 1x COM, Audio; 4x
USB3.1 Gen2 (Type A); 2x USB3.1
(Type C) backside; 2x USB3.1
(Type A) frontside; 1x USB3.1
(Type A) internal; Temperature
and fan monitoring, Watchdog,
card retainer;
Core i7-8700 (6C/12T, 3.2 (4.6)
GHz, 12 MB cache,TB, AMT) PCS 7
OS server, engineering server,
web server;
1 TB HDD [Enterprise] 3.5 SATA;
drive support for internal
installation, 0.5 g vibration,
5 g shock;
32 GB DDR4 SDRAM (2x 16 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), 64-bit,
without restore USB flash
drive;
bus module 4 slots: 2x PCI, 2x
PCIe x16 (8 L);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC System Expansion Card,
up to 1000 process objects and
V10 license for PCS neo,
suitable for CPU 410-5H and CPU
4168-H

SIMATIC Process Control System
IPC847E; (Rack PC, 19, 4U),
Interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x Display Port; 1x
COM, Audio; 4x USB3.1 Gen2
(Type A); 2x USB3.1 (Type C)
backside; 2x USB3.1 (Type A)
frontside; 1x USB3.1 (Type A)
internal; Temperature and fan
monitoring, Watchdog, card
retainer;
Xeon E-2278GE (8C/16T, 3.3
(4.7) GHz, 16 MB cache, TB,
AMT) - PCS 7 OS server,
engineering server, web server;
RAID5, approx. 3.8 TB (3 x 1920
GB SSD 2.5 SATA);
drive support for rack units on
the front;
32 GB DDR4 SDRAM (2x 16 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), with restore
USB flash drive;
bus module 11 slots: 3x PCI, 1x
PCIe x16 (8 L), 5x PCIe x16 (4
L), 2x PCIe x4 (4 L);
2x 100/240 V AC redundant
Industrial power supply unit,
power supply cord USA;

SIMATIC Process Control System
IPC847E; (Rack PC, 19, 4U),
Interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x Display Port; 1x
COM, Audio; 4x USB3.1 Gen2
(Type A); 2x USB3.1 (Type C)
backside; 2x USB3.1 (Type A)
frontside; 1x USB3.1 (Type A)
internal; Temperature and fan
monitoring, Watchdog, card
retainer;
Xeon E-2176G (6C/12T, 3.7 (4.7)
GHz, 12 MB cache, TB, AMT) -
PCS 7 OS server, engineering
server, web server;
RAID1, 2x 960 GB SSD 2.5 SATA;
drive support for rack units on
the front;
32 GB DDR4 SDRAM (2x 16 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), with restore
USB flash drive;
bus module 11 slots: 3x PCI, 1x
PCIe x16 (8 L), 5x PCIe x16 (4
L), 2x PCIe x4 (4 L), BCE;
2x 100/240 V AC redundant
Industrial power supply unit,
power supply cord USA;

SIMATIC PCS neo V5.0 software
Process Device Manager (100
field objects), license
floating license for 1 user
engineering software without
software, without
documentation, class A, 2
languages (de, en), executable
in Windows Server 2019 Standard
Edition (64-bit MUI), for more
information, see PCS neo V5.0
system Readme, reference
hardware: PCS neo V5.0 IPC
bundle content: 1x certificate
order only in connection with:
6DL8900-7XX00-0XB8-Z Y01 Y02

SIMATIC PCS neo V5.0 software
Process Device Manager license
floating license for 1 user
engineering software without
software, without
documentation, class A, 2
languages (de, en), executable
in Windows Server 2019 Standard
Edition (64-bit MUI), for more
information, see PCS neo V5.0
system Readme, reference
hardware: PCS neo V5.0 IPC
bundle content: 1x certificate
order only in connection with:
6DL8900-7XX00-0XB8-Z Y01 Y02

SIMATIC PCS neo V5.0 software
Process Objects (100 PO),
license floating license for 1
user engineering software
without software, without
documentation, class A, 2
languages (de, en), executable
in Windows Server 2019 Standard
Edition (64-bit MUI), for more
information, see PCS neo V5.0
system Readme, reference
hardware: PCS neo V5.0 IPC
bundle content: 1x certificate
order only in connection with:
6DL8900-7XX00-0XB8-Z Y01 Y02

SIMATIC process control system
IPC547J; (rack PC, 19, 4 U),
interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x display port; 1x
COM, audio; 6x USB 3.1 Gen. 2
(2x type C, 4x type A) on the
rear side, 2x USB3.1 Gen.1
(type A) on the front, 2x USB
2.0 internal; 7 slots: 5x PCIe,
2x PCI, internal, temperature
and fan monitoring watchdog,
card retainer;
Core i7-10700E (8C/16T, 2.9
(4.5) GHz, 16 MB cache), MB
(Chipset W480E), iAMT, PCS 7
ES/OS Single Station, OS
client;
1 TB HDD [Enterprise] 3.5 SATA;
drive support for internal
installation, 0.5 G vibration,
5 g shock;
16 GB DDR4 SDRAM (2x 8 GB),
dual channel;
PCS 7 V9.1 SP1 preinstalled;
Windows 10 IoT Enterprise 2019
LTSC, MUI (en, de, fr, it, sp,
zh), 64-bit, without restore
USB flash drive, (for Processor
Core i7 / Xeon);
enclosure blue chromated,
Industrial Ethernet (CP1623),
(1 slot occupied);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC847E; (Rack PC, 19, 4U),
Interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x Display Port; 1x
COM, Audio; 4x USB3.1 Gen2
(Type A); 2x USB3.1 (Type C)
backside; 2x USB3.1 (Type A)
frontside; 1x USB3.1 (Type A)
internal; Temperature and fan
monitoring, Watchdog, card
retainer;
Core i5-8500 (6C/6T, 3.0 (4.1)
GHz, 9 MB cache, TB, AMT) - PCS
7 ES/OS Single Station, OS
Client;
RAID1, 2x 2 TB HDD [Enterprise]
3.5 SATA + 2 TB HDD
[Enterprise] 3.5 SATA as hot
spare;
drive support for installation
internal, 0.5 g vibration, 5 g
shock, 1024 GB SSD M.2 NVMe to
PCIe x4 adapter card (1 slot
occupied) (for operating
system);
16 GB DDR4 SDRAM (2x 8 GB),
Dual Channel;
without pre-installation;
Windows 10 Enterprise 2019
LTSC, MUI (en, de, fr, it, sp,
zh), 64-bit, with restore USB
flash drive;
bus module 11 slots: 3x PCI, 1x
PCIe x16 (8 L), 5x PCIe x16 (4
L), 2x PCIe x4 (4 L),
Industrial Ethernet (CP1623),
(1 slot occupied),
multi-monitor 4-5 screens,
combined, onboard interfaces (2
x DP) + PCIe x16 graphics card
(3x mDP: 3x adapter mDP
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC647E; (Rack PC, 19, 2U),
Interfaces: 3x Gbit LAN (RJ45),
M.2 PCIe x4 1x DVI-D, 2x
Display Port; 1x COM, Audio; 4x
USB3.1 Gen2 (Type A); 2x USB3.1
(Type C) backside; 2x USB3.1
(Type A) frontside; 1x USB3.1
(Type A) internal; Temperature
and fan monitoring, Watchdog,
card retainer;
Xeon E-2176G (6C/12T, 3.7 (4.7)
GHz, 12 MB cache,TB, AMT) PCS 7
ES/OS Single Station, OS
Client;
RAID1, 2x 960 GB SSD 2.5 SATA;
drive support for internal
installation, 0.5 g vibration,
5 g shock; 1024 GB SSD M.2 NVMe
(M.2 slot occupied) (for
operating system);
32 GB DDR4 SDRAM (2x 16 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), 64-bit,
without restore USB flash
drive;
bus module 4 slots: 2x PCI, 2x
PCIe x16 (8 L), Industrial
Ethernet (CP1623), (1 slot
occupied);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC847E; (Rack PC, 19, 4U),
Interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x Display Port; 1x
COM, Audio; 4x USB3.1 Gen2
(Type A); 2x USB3.1 (Type C)
backside; 2x USB3.1 (Type A)
frontside; 1x USB3.1 (Type A)
internal; Temperature and fan
monitoring, Watchdog, card
retainer;
Core i5-8500 (6C/6T, 3.0 (4.1)
GHz, 9 MB cache, TB, AMT) - PCS
7 OS server, engineering
server, web server;
RAID1, 2x 1 TB HDD [Enterprise]
3.5 SATA;
drive support for installation
internal, 0.5 g vibration, 5 g
shock;
16 GB DDR4 SDRAM (2x 8 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), with restore
USB flash drive;
bus module 11 slots: 3x PCI, 1x
PCIe x16 (8 L), 5x PCIe x16 (4
L), 2x PCIe x4 (4 L);
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC847E; (Rack PC, 19, 4U),
Interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x Display Port; 1x
COM, Audio; 4x USB3.1 Gen2
(Type A); 2x USB3.1 (Type C)
backside; 2x USB3.1 (Type A)
frontside; 1x USB3.1 (Type A)
internal; Temperature and fan
monitoring, Watchdog, card
retainer;
Xeon E-2176G (6C/12T, 3.7 (4.7)
GHz, 12 MB cache, TB, AMT) -
PCS 7 OS server, engineering
server, web server;
RAID1, 2x 1 TB HDD [Enterprise]
3.5 SATA;
drive support for rack units on
the front;
32 GB DDR4 SDRAM (2x 16 GB),
Dual Channel;
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), with restore
USB flash drive;
bus module 11 slots: 3x PCI, 1x
PCIe x16 (8 L), 5x PCIe x16 (4
L), 2x PCIe x4 (4 L), BCE;
100/240 V AC industrial power
supply unit, power supply cord
USA;

SIMATIC Process Control System
IPC847E; (Rack PC, 19, 4U),
Interfaces: 3x Gbit LAN (RJ45),
1x DVI-D, 2x Display Port; 1x
COM, Audio; 4x USB3.1 Gen2
(Type A); 2x USB3.1 (Type C)
backside; 2x USB3.1 (Type A)
frontside; 1x USB3.1 (Type A)
internal; Temperature and fan
monitoring, Watchdog, card
retainer;
Xeon E-2278GE (8C/16T, 3.3
(4.7) GHz, 16 MB cache, TB,
AMT) - PCS 7 OS server,
engineering server, web server;
RAID5, approx. 5.7 TB (4 x 1920
GB SSD 2.5 SATA);
drive support for rack units on
the front, 1024 GB SSD M.2 NVMe
to PCIe x4 adapter card (1 slot
occupied) (for operating
system);
64 GB DDR4 SDRAM (4x 16 GB),
ECC, dual channel, (only with
Xeon processor);
PCS 7 V9.1 pre-installed;
Windows Server 2019 standard
edition including 16 cores, 5
clients, 64-bit, MUI (en, de,
fr, it, sp, zh), with restore
USB flash drive;
bus module 11 slots: 3x PCI, 1x
PCIe x16 (8 L), 5x PCIe x16 (4
L), 2x PCIe x4 (4 L);
2x 100/240 V AC redundant
Industrial power supply unit,
power supply cord USA;
